DUTCH CONE PENETROMETER / Sondir 5 Ton; ASTM D-3441
According SNI
Consist of :
Press-In Apparatus ( 1 set)
Steel construction, manually operated 5 tons capacity.
A Sounding Rod ( 20 pcs)
Machined steel, 36 mm o.d., 1 mtr effective length, tappered thread.
Plunger Rod; round bar, 15 mm dia, 1 mtr length ( 20 pcs)
Adaptor
Consist of :
.1 Push Adaptor; machined steel ( 1 pc)
2 Pull Adaptor; machined steel ( 1 pc)
Spiral Anchor
Consist of :
.1 Spiral Anchor; machined steel, welded 1.5 m length ( 4 pcs)
.2 Handle And T-piece; machined steel, welded ( 4 pcs)
A Mantel Cone ( 1 set)
Precision machine steel hardened tip, tappered thread 60 angle,
35.7 mm diameter.
A Friction Cone ( 1 pc)
Precision machine steel hardened, with friction jacket,
tappered thread 60 angle, 35.7 mm diameter.
Wrenches Set ( 1 set)
Pipe wrench ( 2) , adjustable wrench ( 1) , spanner wrench ( 1)
allen key ( 1) , screw driver ( 1) , oil can ( 1) , steel brush ( 1) ,
piston wrench ( 1) , seals tape ( 2) , oil seals ( 2) , steel box ( 1) .
Fasten press; beam Cannal.
Consist of :
.1 Long Fasten Press; 1.8 m length, 12 cm width ( 2 pcs)
.2 Short Fasten Press; 1.2 m length, 15 cm width ( 2 pcs)
Manometer; 60 kg / cm2 capacity ( 1 pc)
Manometer; 500 kg/ cm2 capacity ( 1 pc)
Dimension ( l x w x h) : 220 x 12
Jawa Barat - Bandung
