Heavy-duty welded steel construction 30 cm,
(profile steel columns 10 thick botttom and upper plate)
Hydraulic System
For 1500 kN Cap.
Cast iron cylinder,
Hard-chromed piston, 230 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 280 mm dia. x 320 mm height
Single action, gravity return
Hydraulic System
For 2000 kN Cap.
Cast iron cylinder,
Hard-chromed piston, 230 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 300 mm dia. x 320 mm height
Single action, gravity return
Hydraulic System
For 3000 kN Cap.
Cast iron cylinder,
Hard-chromed piston, 250 mm diameter
Maximum working pressure 50.000 kPa
Overall dimension 330 mm dia. x 320 mm height
Single action, gravity return
Hydraulic Pump
Electric, 220 V AC, 50-60 HZ, 1000 Watt, 1 Phase
Single action, variable speed
6.000 ml reservoir capacity
Maximum working pressure 50.000 kPa
Single action, gravity return
Force Gauge
Bourdon tube manometer, 280 mm dial diameter
With maximum load pointer. Steel box housing.
Calibrated by JNK
Compressive
Platen
Upper : 180 x 180 mm, ball seating
Lower : 250 mm diameter
Clearance
Horizontal: 290 mm
Vertikal : 310 mm
Dimension
760 x 320 x 1400 mm (l x w x h) approx.
Weight
500 kg,
RC-325.3
Compression Machine
1500 kN capacity,
10 kN increments
RC-325.4
Compression Machine
2000 kN capacity,
10 kN increments
RC-325.5
Compression Machine
3000 kN..
